Oehlbach Phono PreAmp Pro

990 kr

Oehlbach Phono PreAmp Pro
Low-distortion phono amplifier for record players with MM or MC pickup

The Phono PreAmp Pro from Oehlbach integrates your record player with an MM or MC cartridge into existing high-quality hi-fi components without a dedicated phono input.

The low-noise pre-amp is fitted with gold-plated contacts to guarantee a stable and reliable connection between the phono device and the hi-fi system. Equipped with an external power supply, the Phono PreAmp Pro weights just 100 g and easily fits into any hi-fi rack thanks to its compact design. The individual components are connected via analogue stereo RCA connectors.

# 24-karat gold-plated contacts
# For moving-magnet pick-up
# For moving-coil pick-up
# Power supply via external power supply unit

Specifikation:
# Operating current: < 100 mA
# Output voltage: (MM) / (MC) 600 mV
# Input sensitivity: (MM) 5mV / (MC) 0,5mV
# Balance des canaux: (MM) < 0,5 dB / (MC) < 0,5 dB
# Channel Separation: > 70 dB (MM), > 60 dB (MC)
# Voltage supply: 18V/DC, 150 mA
# Distortion: (MM) < 0,1 % / (MC) < 0,1 %
# Signal-to-noise ratio: >72 dB (MM); >60 dB (MC)
# Input impedance: (MM) 50 Ohms (MC) 100 Ohms

# Dimensions: 94x24x64mm
# Weight: 0,1 kg
